Resolution
|
|
|
|
Driver resolutions for older Robustelli models
Warning
The following information is based on provided data, and due to the device's age, compatibility cannot be assured.
Some older models are compatible with this driver; however, unexpected behavior may require manual adjustments, particularly regarding resolutions.
To add resolutions on these devices, an additional XML file must be configured. Edit the file located at /opt/caldera/lib/DRIVERS/MISC/Epson-Monna-Lisa.res.xml.
In this file, include the required resolutions along with the appropriate values for the X and Y paths (multiples of the head resolution).
Loading
- Roll 3.2m
- Roll 2.2m
- Roll 1.8m
- Custom (...)
Media
This driver comes with only a default media not calibrated.
Discover how to manage media with EasyMedia by clicking here.
Mode
Info
Other modes with more inks must be configured in EasyMedia, according to your ink configuration.
- CMYK
Quality
|
|
Action
The device supports only two actions:
- Print.
- Nest.
"Rip", "Rip then Print", and "Keep the ripped file" actions are disabled, as the "Print" action sends a RIP file to the controller-mounted directory. You can keep RIP files in the controller and manage to reprint them on the controller directly.
