Resolution
Info
"VD" Stands for Variable Drop (2bpp 3 drops)
-
600x600-VD
-
600x1200-VD
-
600x1800-VD
-
600x2400-VD
Loading
- Roll 3200mm
- 3200x1500mm (only FB3215-06DW2ZL driver)
- Custom (...)
Media
This driver comes with only a default media not calibrated.
Discover how to manage media with EasyMedia by clicking here.
Mode
- CMYK
- CMYKcm
Quality
- Bi-dir
- Uni-dir
- Bi-dir Double Strike
- Uni-dir Double Strike
Double Strike: each dot is fired twice, and multiply the resolution passes by 2, which can lead to a theoretical 200% density compared to the original qualities.
Action
The device supports only two actions:
- Print.
- Nest.
"Rip", "Rip then Print", and "Keep the ripped file" actions are disabled, as the "Print" action sends a RIP file to the controller-mounted directory. You can keep RIP files in the controller and manage to reprint them on the controller directly.
