Modes
Info
Printer driver(s) compatible with Custom Inksets. For more information, partners and resellers should consult the Partners Portal; end users can find details on our website.
All three models support the following modes:
- CMYK
- CMYKk
- CMYKcm
- CMYKcmk
- CMYKO
- CMYKOGV
By default, four Special Inks are linked to the printer:
- Primer
- Varnish
- White Underlay
- White Overlay
For more information on how to use these special inks, please refer to the Spot Inks article.
Loading
- Roll
- Sheet
- Custom (How to use CustomLoading?)
Resolutions
Info
2L stands for 2 Levels. This mode uses binary printing, meaning that each printed dot is either present or absent, unlike grayscale printing, which uses multiple drop sizes or density levels to reproduce tones.
| Impala | Impala-i | Nyala | Oryx | |
|---|---|---|---|---|
| 450x720-2L |
✔ | ✔ | ✔ | |
| 540x720-2L |
✔ | ✔ | ✔ | |
| 720x360-2L | ✔ | ✔ | ✔ | |
| 720x720-2L | ✔ | ✔ | ✔ | ✔ |
| 900x720-2L | ✔ | ✔ | ✔ | ✔ |
| 900x1080-2L |
✔ | ✔ | ✔ | ✔ |
| 1080x720-2L |
✔ | ✔ | ✔ | ✔ |
| 1080x360-2L |
✔ | |||
| 1080x1080-2L |
✔ | ✔ | ✔ | ✔ |
Qualities
Info
Custom qualities can be defined by the operator in the Amber controller. There is a distinction between qualities and materials. Qualities are predefined pass settings, which are used in combination with materials. Materials correspond to profiled media. All custom qualities and materials can be defined by the operator in the Amber controller.
FA stands for Fine Art.
| 450x720-2L | 540x720-2L | 720x360-2L | 720x720-2L |
|
|
|
|
| 900x720-2L | 900x1080-2L | 1080x720-2L | 1080x360-2L |
|
|
|
|
| 1080x1080-2L | |||
|
Actions
As these printers use a controller, the printer drivers support only the following two actions:
- Nest
In this sense, these printer drivers do not support “RIP”, “RIP then Print”, or “Keep Ripped File”.
