Resolution
| Agfa-Avinci-CX3200-4C | Agfa-Avinci-CX3200-6C | |
|
300x300 |
✔ | |
|
300x600 |
✔ | ✔ |
|
300x900 |
✔ | |
| 300x1200 | ✔ | ✔ |
| 300x1800 | ✔ | |
| 450x300 | ✔ | |
| 450x600 | ✔ | ✔ |
| 450x900 | ✔ | |
| 450x1200 | ✔ | ✔ |
| 450x1800 | ✔ | |
| 600x300 | ✔ | |
| 600x600 | ✔ | ✔ |
| 600x900 | ✔ | |
| 600x1200 | ✔ | ✔ |
| 600x1800 | ✔ |
Loading
- Roll 3320mm
- Custom (...)
Custom loading with EasySelect
EasySelect is the capability for CalderaRIP to use the size and type of loaded media in the printer.
This printer supports 1 level of selection:
- CustomLoading: uses a custom size (sheet or roll) defined at last moment in the Print module interface.
Media
- Plain paper (default)
This driver comes with only a default media not calibrated.
Discover how to manage media with EasyMedia by clicking here.
Mode
- CMYK
- CMYKmc (only with the 6C driver)
Quality
- Normal-Bi (Bidirectional)
- Normal-Uni (Unidirectional)
Actions
The device supports only two actions:
- Print.
- Nest.
"Rip", "Rip then Print", and "Keep the ripped file" actions are disabled, as the "Print" action sends a RIP file to the controller-mounted directory. You can keep RIP files in the controller and manage to reprint them on the controller directly.
