Resolution
Click here to see all resolutions available
| Scitex 9000 | Scitex 11000 | Scitex 15500 | Scitex 17000 | |
| UniSample | ✓ | |||
| UniSample Wide | ✓ | |||
| UniText | ✓ | |||
| UniText Wide | ✓ | |||
| Smooth Backlit | ✓ | |||
| Smooth Backlit Wide | ✓ | |||
| Sample | ✓ | ✓ | ✓ | |
| Sample Wide | ✓ | ✓ | ✓ | |
| Backlit | ✓ | |||
| Backlit Wide | ✓ | |||
| Text | ✓ | ✓ | ||
| Text Wide | ✓ | ✓ | ||
| Fast Sample | ✓ | |||
| Fast Sample Wide | ✓ | |||
| HQ POP | ✓ | ✓ | ✓ | |
| HQ POP Wide | ✓ | ✓ | ✓ | |
| POP Production | ✓ | ✓ | ✓ | |
| POP Production Wide | ✓ | ✓ | ✓ | |
| Production | ✓ | ✓ | ||
| Production Wide | ✓ | ✓ | ||
| Fast Production | ✓ | ✓ | ||
| Fast Production_Wide | ✓ | ✓ | ||
| Display | ✓ | |||
| Display Wide | ✓ | |||
| Display WG | ✓ | |||
| Display WG Wide | ✓ | |||
| Packaging | ✓ | |||
| Packaging Wide | ✓ | |||
| Draft | ✓ | |||
| Draft Wide | ✓ | |||
| Packaging WG Gloss | ✓ | |||
| Packaging WG Gloss Wode | ✓ | |||
| Display Text | ✓ | |||
| Display Text Wide | ✓ |
Loading
- 3200x1524 mm
- 3200 x 1600 mm
- Custom (...)
Custom loading with EasyMedia
EasySelect is the capability for CalderaRIP to use the size and type of loaded media in the printer.
This printer supports 1 level of selection:
- CustomLoading: uses a custom size (sheet or roll) defined at last moment in the Print module interface.
Media
This driver comes with only a default media not calibrated.
Discover how to manage media with EasyMedia by clicking here.
Mode
- CMYK
- CMYKcm (only on 9000 / 11000 / 15500)
Appearance
Info
The following values are dynamic and depend on the selected resolution.
| Scitex 9000 | Scitex 11000 | Scitex 15500 | Scitex 17000 | |
| Default | ✓ | ✓ | ✓ | ✓ |
| 80% All (HDR250) | ✓ | |||
| Corrugated 70 (HDR250) | ✓ | |||
| Corrugated for Varnish (HDR250) | ✓ | |||
| Corrugated Satin 70 (HDR250) | ✓ | |||
| Corrugated (HDR250) | ✓ | |||
| Gloss (HDR230) | ✓ | |||
| Plastic Matte (HDR250) | ✓ | ✓ |
Saturation
Info
The following values are dynamic and depend on the selected resolution.
| Scitex 9000 | Scitex 11000 | Scitex 15500 | Scitex 17000 | |
| 100% | ✓ | ✓ | ✓ | ✓ |
| 110% | ✓ | ✓ | ||
| 120% | ✓ | ✓ | ||
| 130% | ✓ |
Action
The device supports only two actions:
- Print.
- Nest.
"Rip", "Rip then Print", and "Keep the ripped file" actions are disabled, as the "Print" action sends a RIP file to the controller-mounted directory. You can keep RIP files in the controller and manage to reprint them on the controller directly.
