Supported models
|
UG-641 (64") |
UG-642 (64") |
- Large format printers with an integrated cutter for Print-and-Cut. More info
- These printers are available in 4 to 6-ink configurations
- Visit the official website of Roland
Drivers
|
|
Driver history
-
CalderaRIP V17.3
- Roland SP (VisualCut driver for these devices): Optimization of the cutting order when using "Instant Cutting", as well as the integration of tools configuration (using a VisualCut export).
- Roland DGXPRESS-UG642: A new driver has been developed for printers with an inverted print head configuration (GLWCMYK).
-
CalderaRIP V16.2
- The Roland DGXPRESS UG Series is supported since this version
Inks
| Configuration 1 | Configuration 2 | |
| Cyan | ✔ | ✔ |
| Magenta | ✔ | ✔ |
| Yellow | ✔ | ✔ |
| Black | ✔ | ✔ |
| Gloss / Varnish | ✔ | |
| |
✔ |
Info
- Do not forget to use the driver that corresponds to the ink configuration of your printer.
- Caldera and Roland have different ways of abbreviating the colors, here is the nomenclature:
- "W" and "Wh" = White
- "GL" and "Gloss" = Varnish
- The CMYKGLW configuration enables Varnish and White as Spot Inks. Learn more with this dedicated article.
Connection
| USB | |
| File | |
| Network | |
| Serial |
Tips and Tricks
Immediate Cut is available in the Cutting tab of the Page Setup when selecting the Roland SP cutting driver.
