Modes
Info
Printer driver(s) compatible with Custom Inksets. For more information, partners and resellers should consult the Partners Portal; end users can find details on our website.
Most models support the following modes:
- CMYK
- CMYKk
- CMYKcm
- CMYKcmk
- CMYKO
- CMYKOGV
Excepted for S models (Impala-4S-i, Nyala-4S-i), which only support CMYK.
Tips & tricks
If you want to use a mode based on CMYKc, select the CMYKcm mode. In the printer settings, the Light Magenta ink must still be mapped in the ink reordering; otherwise, an error message will appear. However, because this channel is not actually used, only the CMYKc inks will be addressed.
By default, four Special Inks are linked to the printers:
- Primer
- Varnish
- White Underlay
- White Overlay
For more information on how to use these special inks, please refer to the Spot Inks article.
Loading
- Roll
- Sheet
- Custom (How to use CustomLoading?)
Resolutions
Info
2L stands for 2 Levels. This mode uses binary printing, meaning that each printed dot is either present or absent, unlike grayscale printing, which uses multiple drop sizes or density levels to reproduce tones.
| Impala-4 | Impala-4-i | Impala-4S-i | Nyala-4 | Nyala-4-i | Nyala-4S-i | Oryx-4-i | |
|---|---|---|---|---|---|---|---|
| 540x720-2L | ✔ | ✔ | |||||
| 720x720-2L | ✔ | ✔ | ✔ | ✔ | ✔ | ||
| 900x720-2L | ✔ | ✔ | ✔ | ||||
| 900x900-2L | ✔ | ✔ | |||||
| 900x1080-2L | ✔ | ✔ | ✔ | ||||
| 1015x450-2L | ✔ | ✔ | |||||
| 1015x900-2L | ✔ | ✔ | |||||
| 1080x360-2L | ✔ | ✔ | ✔ | ||||
| 1080x720-2L | ✔ | ✔ | ✔ | ✔ | ✔ | ||
| 1080x1080-2L | ✔ | ✔ | ✔ | ||||
| 1350x450-2L | ✔ | ✔ | |||||
| 1350x900-2L | ✔ | ✔ | |||||
| 1350x1350-2L | ✔ | ✔ |
Qualities
Info
Custom qualities can be defined by the operator in the Amber controller. There is a distinction between qualities and materials. Qualities are predefined pass settings, which are used in combination with materials. Materials correspond to profiled media. All custom qualities and materials can be defined by the operator in the Amber controller.
FA stands for Fine Art.
| 540x720-2L | 720x720-2L | 900x720-2L | 900x900-2L |
|
|
|
|
| 900x1080-2L | 1015x450-2L | 1015x900-2L | 1080x360-2L |
|
|
|
|
| 1080x720-2L | 1080x1080-2L | 1350x450-2L | 1350x900-2L |
|
|
|
|
| 1350x1350-2L | |||
|
Actions
As these printers use a controller, the printer drivers support only the following two actions:
- Nest
In this sense, these printer drivers do not support “RIP”, “RIP then Print”, or “Keep Ripped File”.
