When creating jobs for your roll-to-roll cutter (VisualCut), some settings must be done at the last minute in the Print Module.
To do so, go to Page Setup > Cutting tab:
This tab is divided into the following areas:
Recommendation
We recommend that you visit each dedicated article to learn more about the possible configurations.
- Preview: The Preview area is located on the left side of the Page Setup window. This is where you see your image placed on the media.
- Enable cutting contour: This is where you enable the cutting features and where you select your cutter driver. Check the box next to Enable Cutting Contour to activate the cut features.
- Instant Cutting: This is where you select the action to print and instantly cut.
- Registration Marks: The Registration marks area has cutting features specific to Cut Marks. Click the "plus cross" to display all settings.
Info
If a feature is enabled but is grayed out, then that feature is not activated. This is caused by having two features enabled that are conflicting.
Example: When enabling Edges registration marks and then enabling Instant cut just after print, the Edges registration marks gray out, and the feature applied to the graphic is Instant cut just after print.
- Barcodes: The Barcodes area has cutting features specific to Barcodes and QR Codes. Click the "plus cross" to display all settings.
- Contours: The Contours area is where you manage the actions for each cutting contour that appears in the graphic. Note that some contours might not be compatible with Contour Nesting (more details in the related articles).
