Epson SureColor S30600, S50600 and S70600 - Profile specifications

Resolution

Available resolutions:

360x360 (only for the S70600)- 360x720 - 720x720 - 720x1440 - 1440x1440

In addition to the standard resolutions, composed resolutions also exist.

Mode

The printer has eight basic inks: Cyan, Magenta, Yellow, Black, Light cyan, Light magenta, Light black and Orange and two additional inks: White and Metallic Silver(only for the S70600).

Print modes available:

only for the S70600:Some of the previous modes are also available using silver (CMYKcmk + silver for example).

The word “colors” represents the mode that has been chosen including NColor with Orange ink.

Quality

The qualities are divided into two categories: unidirectional and bidirectional. Bidirectional means that the head prints in both pass. In Unidirectional quality, the head prints a stripe then move to its original position before printing the next stripe.

Qualities are distinguished by their print level. The level number represents the number of passes done by the head on one printed stripe. The higher the pass number, the higher the quality.

Depending on the quality chosen, the number and the characteristics of the levels vary.

Changing a profile generated with CMYK8 mode

Previous profiles created with the CMYK8 mode have to be changed. Indeed, CMYK8 is the former name of the mode that used the Epson raster. It has to be replaced by EpsonHTM CMYK modes to be still available. Please follow this procedure to modify the profiles without any extra calculation or target measurement.

1. Open EasyMedia* and select your Epson SureColor S30600, S50600 or S70600 device.

The following steps will have to be repeated for every media that has profiles using the CMYK8 mode.

^*EasyMedia is named ProfileExpert in the TextilePro interface.

2. Double-click on your media to open its profile list.
3. Select your profile then click on the Edit… button.
4. Change the profile mode according to the following rule: use EpsonHTM CMYKcmkO or CMYKcmko for the S70600 mode
5. Click then on OK to save the change. The following message will appear to inform you that it is not recommended to change a profile printing mode. Click on Yes to confirm the change and end the procedure.

Repeat this operation to all profiles that use the CMYK8 mode.
