Supported models
|
|
|
|
|
|
Info
If you have any of the following models, please refer to their specific documentation:
Driver
- Mimaki (generic driver)
Driver history
- CalderaRIP V9.20
- The Mimaki generic driver is supported since this version
Installation
Type of license
| CutServer | |
| GrandCut (A/B) |
These devices are VisualCut cutters:
Marks
Standard barcode numbers are applicable from Page setup > Cutting tab, under the Barcodes area.
Features
VisualCut
The following options are available in the VisualCut interface:
- Rewind at end
- Sheet off
For more information, please refer to this article.
Cutter tools configuration
The Auto-rotate job option is available from the Cutter tools configuration.
Associations
This driver is a connected cutter (VisualCut)
- No materials and methods association
- No materials and media association
- No methods and contours association by material
Despite the above, you can use the tools list to associate contour names with a given tool. If more than one material is used, you can save and reload different tool lists.
Connection
Info
All models support USB. The CG-SRIII series also supports Ethernet, but please refer to Mimaki documentation directly for more information.
| USB | |
| File | |
| Network | |
| Serial |
Tips & tricks
Cutting procedure (to avoid double mark detection)
- Insert the media
- Select Roll (Back)
- Cancel marks detection with "End"
- Position the tool in the bottom-left mark (inside the "square")
- Set the origin with "Enter" or "Origin"
- Single with marks
- Rotate the job in VisualCut as you see it when in front of the cutter
- Cut
